Ecotech marine VorTech MP60W Propeller Pump
Ecotech marine VorTech MP60W Propeller Pump
SKU:SKU MP60WQD
VorTech MP60W Propeller Pump
The award-winning technology of the MP60W provides wireless operation on tanks between 450 and 3800+ litres, producing 3,500 to 7,500 gallons per hour of flow and smallest in-tank footprint for full-size reef aquariums.
The Wireless Wave Driver enables wireless coordination and enhanced functionality between multiple VorTech units right out of the box, with no extra equipment to buy—making it the most effective solution on the market for larger aquariums
Specifications
Flow: 3,500-7,500 gallons per hour (13,000 – 28,000 liters per hour)
Power Consumption: 10-60 watts
Maximum Motor Temperature: 50-60 degrees Celsius
Aquarium Wall Thickness Range: 3/16″-3/4″ (4.76mm – 19mm)
Appropriate Tank Size Range: 120-1000+ gallons (450 -3,800+ liters)
Dimensions: Wet Side- 3″ diameter by 2.25″ long (76mm x 57mm),
Dry Side- 84mm″ diameter by 2.25″ long (76mm x 57mm)
Clearance Needed Behind Aquarium: 3″ (76mm)
Operational Modes
Constant Speed Mode - Pump runs continuously at a constant speed which can be set by the user.
EcoSmart Nutrient Transport Mode (NTM) - A two phase program to promote maximum health and nutrient export, as well as increased growth for corals. Alternates between a resonant standing wave and a surge effect to stir up and export nutrients.
EcoSmart Tidal Swell Mode (TSM) - Creates a harmonic balance in your aquarium reminiscent of the changing flow conditions that would be found in nature. Flow varies from left to right, right to left, calm, and ends with a great surge.
Reef Crest Random Mode - Reef Crest Random Mode simulates the high-energy conditions of a natural reef crest environment.
Lagoonal Random Mode - Simulates the gentler reef zone found in a natural lagoon.
Short Pulse Mode - Allows for wave pulse timings between 0.3 and two seconds, enabling the creation of FAST alternating flow throughout the tank. Use this mode to create a resonant standing wave.
Long Pulse Mode - Allows for wave pulse timings of between 2 seconds and 60 seconds, enabling the creation of slow alternating flow throughout the tank.
Feed Mode - Slows down pump to allow user to feed aquarium. User can select the duration and speed for Feed Mode.
Night Mode - Automatically reduce speed and operates continuously at that speed for a period of time during the night. User can select the duration and speed for Night Mode.
Battery Backup Mode - When used with our battery backup accessory, the VorTech pump will switch to Battery Backup Mode in the event of a power outage and will operate at a user set speed. The LED’s on your EcoSmart driver will count down to indicate how much power is available within the battery.
Auto-Dim - LED’s are turned off and display knob dimmed significantly, but pump functions in its current mode. User can program how long after use before the driver enters Auto-Dim.
On/Off Switch - Tap the on/off switch to turn off and turn on a pump. Hold this button to turn off all pumps in a master/slave group. Tap any pump in the groups’ on/off switch and that pump will turn back on.
